UVS-1240U4-16 Geovision 16 Channel DVR 240FPS @ 720 x 480 - No HDD

Features:

• Model Number: UVS-1240U4-16
• Manufacturer Part Number: 95-24BU4-160
• Sales Part Number: 377-124U4B-016

Specifications

• System Models - 1240
• Hot Swap Bays - 4/ 8/ 10/ 20
• CPU - Intel i7 Haswell (4th Gen.)
• Memory (RAM) - 16 GB DDR3
• Video
  • Codec - Software: Geo MPEG4, Geo MPEG4 (ASP), Geo H.264, Geo H.264 V2
  • Input - 16
• Video Loop (optional) - 16
• Audio
  • Compression - ADPCM , G.723, AAC (16 kHz / 16 bit)
  • Input - 16
• Display Frames (total)
  • NTSC - 480
  • PAL - 400
• Recording Frames (total)
  • NTSC - 120
• Recording at (CIF)
  • PAL - 100
• Video Resolution
  • NTSC - 320 x 240, 360 x 240, 640 x 480, 640x 480 De-interlace, 720 x 480, 720 x 480 De-interlace
  • PAL - 320 x 240, 360 x 288, 640 x 480, 640 x 480 De-interlace, 720 x 576, 720 x 576 De-interlace
• Recovery DVD - DVD±R, DVD±RW, CD-R/RW
• Backup Type - Automatic System Rebuild
• Alarm Inputs
  • Sensor Input - 4*
  • Alarm Output - 4*
• Connector
  • Ethernet - 2 x RJ-45, 10/100/1000 Mbps
  • VGA Output - 2 (DVI, VGA, or HDMI)
  • USB 2.0 (F + R) - 4 monitors: DVIx4 (optional)
  • USB 3.0 - 2 Front + 4 Rear
• Remote Access - TCP/IP, LAN, WAN, Internet, ISDN
• Operating Temperature - 0 to 45 °C (32 to 133 °F)
• Humidity - 0 to 80% RH (non condensing)
• Dimensions (W x D x H)
  • 20 Bays - 19 x 26 x 7 inch
  • 4 and 8 Bays - 19 x 21 x 7 inch
  • 2 Bays - 19 x 21 x 7 inch
• Raid (optional) - 0, 1, 5, 6
• Optional Products - GV-HD-SDI / GV-IO 12-In Card / GV-IO 12-Out Card / GV-IO Box 4 / GV-IO Box 8 / GV-IO Box 16 / GV-Data Capture Box Series / GV-Hub Box / GV-COM Box/ GV-DOM / GV-Joystick / GV-Remote / GV-Keyboard
• Languages - English/ Spanish
