TX-94 Linear Supervised 5-Button 15-Channel Handheld Transmitter

Features:

• Complete RF supervision
• Alarm, supervisory, and low battery transmissions
• Unique "Extra" top button
• High visibility operate LED
• Two type 2032 lithium batteries supplied
• Pocket and belt clip supplied
• SX format
• RF frequency: 303.875 MHz

The Model TX-94 Supervised 5-Button 15-Channel Handheld Transmitter is a supervised, digitally coded radio transmitter designed for use with Linear’s SX Format receivers. Pressing a button on the transmitter sends a digitally coded wireless signal to its companion receiver. To send a complete signal, press the transmitter button for a minimum of 2 seconds. The top button can be hidden with the top button cover supplied.
The TX-94 is a five-button, fifteen-code transmitter. Pressing one of the transmitter’s front buttons sends codes one through four. Pressing the small button on the transmitter’s top sends code five. Pressing the transmitter’s top button together with each front button sends codes six through nine. Pressing the two top front buttons together sends code ten. Pressing the two bottom front buttons together sends code eleven. Pressing the two left front buttons together sends code twelve. Pressing the two right front buttons together sends code thirteen. Pressing the top left and bottom right front buttons together sends code fourteen. Pressing the bottom left and top right front buttons together sends code fifteen.

Specifications

• Power - Two 3V 2032 lithium batteries (supplied)
• Battery Life - Up to five years
• Operating Temperature - 32° to 140° F (0° to 60° C)
• Actuation Indication - LED indicator and tactile feedback
• RF Frequency - 303.875 MHz
• Number of Codes - 16,777,216
• Code Setting Method - Factory programmed
• Dimensions - 1.6" W x 4.2" H x 0.8" D (41 x 107 x 20 mm)
