SK-SE-400-SCM Kantech ioSmart Smart Card Starter Kit with 1 x KT-400 Controller, 3 x KT-MUL-SC Readers, 1 x KT-MUL-MT-KP Reader and Entrapass Special Edition Software

Features:

• Starter kit includes: EntraPass Special Edition software USB key, KT-400 controller (1), KT-MUL-SC readers (3), KT-MUL-MT-KP reader (1), USB-485 converter (1), TR1675 transformer (1), KT-BATT-12 battery (1) and MFP-2KSHL Smart Cards (5)

KT-400 Ethernet-ready four-door controller supports eight readers (EntraPass Security Management Software) and can be configured in two user friendly operational modes. KT-400’s Standalone Mode offers basic door security using a simple web browser without the need to connect to a host system. Alternatively, KT-400 can be used with the powerful EntraPass Security Management Software to provide more advanced and fully integrated access control features.

Specifications

Physical

• Cabinet Dimensions (HxWxD) - 37.6 x 30.5 x 12.6 cm (14.8 x 12.0 x 4.95 in)
• PCB Dimensions (HxWxD) - 23.1 x 14.0 x 3.4 cm (9.1 x 5.5 x 1.3 in)
• Cabinet Weight - 4.0 kg (8.8 lb)

Environmental

• Operating Temperature - 2° to 49° C (35° to 120° F); indoor use only
• Humidity Level - Maximum 85% relative humidity non-condensing

Electrical

• Power Input - KT-400 16.5 VAC or 24 VAC, 75 VA, Class 2 transformer
• Battery Backup - 12 VDC/ 7 or 12 Ah battery supervised; up to 12 hours of operation
• Reader Power Output - Maximum 1.0A @ 5 VDC or 12 VDC, typical 250mA per reader, protected and supervised

Operational

• Reader Types - Wiegand, proximity, ABA clock and data, bar code, magnetic, integrated keypad, smart card
• # of Readers Supported - 8 (EntraPass Security Management Software), 4 (Standalone Mode); Kantech ioProx XSF and ioSmart readers only
• # of Cards when disconnected from EntraPass (Offline Mode) - 100,000 (KT-400 and KT-400-PCB)
• Monitored Points (Inputs) - 16 monitored points, single EOL, double EOL
• Points Maximum Wiring - AWG #22 – 600 m (2,000 ft)
• Door Strike Power - 12 VDC, maximum 2.0A, typical 500mA per lock, supervised
• External Lock Power - 12 or 24 VDC (up to 28 VDC) supply up to 750 mA per lock for a total of 3 amp
• Reader Outputs - 16 outputs, 25 mA maximum each, open collector outputs
• Auxiliary Outputs - LEDs (door 1, door 2, door 3, door 4, LED, OUT1 and OUT2) and buzzers (Buz, door 1, door 2, door 3, door 4) 25 mA each, open collector outputs
• Controlled Output Relay - Four onboard Form C controlled outputs relay, 30 VDC, 3 amp max each
• Communication Ports - RS-232 with RJ-12, RS-485, Ethernet 10/100Base-T with RJ-45
• Expansion Port - SPI 6-pin connector, bi-directional data exchange supported. Supplies 12 VDC, 500 mA maximum shared with 12 VDC auxiliary port
• Auxiliary Port - Auxiliary 12 VDC, 500 mA maximum shared SPI expansion port Communication Speed Up to 115,200 baud (automatic detection over RS-232 and RS-485); 10/100Base-T over Ethernet
• Flash Memory - 256 MB for application and data storage (configuration and events can reside for a minimum of 10 years without power)
• RAM - 128 MB for application loading and running
• Network Autonomy - Distributed data and processing

Regulatory

• EN61000-6-1, EN61000-6-2, EN55032, EN60950-1, EN50130-4, FCC Class B, UL-294, UL-1076, CE, RoHS, WEEE

Warranty

• KT-400 hardware - 5 years
