SD-9963-KSGQ Seco-Larm Post-Mount No-Touch Request-to-Exit Sensor with Access Box

(No reviews yet) Write a Review

$146.10

Brand: Seco-Larm
SKU:: SD-9963-KSGQ
UPC:

Current Stock:

Quantity:

Adding to cart… The item has been added

Description
0 Reviews

Features:

Adjustable sensor range up to 7" (18cm).
Weather resistant for outdoor use.
Stainless-steel face-plate.
Hinged plate easily removes from box for easy wiring.
Adjustable trigger duration 0.8~30 seconds or toggle (ON/OFF).
Form C relay, rated 1A@30VDC.
12~24VDC.
Gooseneck- or wall-mountable.

The ENFORCER Post-Mount No Touch Sensor with Access Box is a full-featured exit plate that uses IR technology to allow egress from a protected area or activate a device with the simple wave of a hand.

Features

Adjustable sensor range up to 7" (18cm).
Weather resistant for outdoor use.
Stainless-steel face-plate.
Hinged plate easily removes from box for easy wiring.
Adjustable trigger duration 0.8~30 seconds or toggle (ON/OFF).
Form C relay, rated 1A@30VDC.
12~24VDC.
Gooseneck- or wall-mountable.
Manual override button.
LED-illuminated sensor area for easy identification.
Selectable LED colors (turns from red to green or green to red) on sensor activation.
Includes heavy-duty steel box.

Specifications

Type - Post-Mount No-Touch Sensor with Access Box
Operating voltage - 12~24 VDC
Current draw

Standby - 16mA@12VDC / 25mA@24VDC
Triggered - 25mA@12VDC / 32mA@24VDC

Relay type - Form C dry contact, 1A@30VDC
Response time - 10ms
LEDs (switchable)

Standby - Red
Triggered - Green

Output time - 0.8~30 s or toggle
Range - 2"~7" (5~18 cm)
IP Rating - front panel only - IP65
Operating temperature - -4º~131º F (-20º~55º C)
Weight - 1-lb 9-oz (710g)
Dimensions - 4"x5-1/2"x3" (102x134x77 mm)

pdficon SD-9963-KSGQ Datasheet

pdficon SD-9963-KSGQ Manual
