RA-4961-MCQ Seco-Larm Wireless Magnetic Contact

Features:

• For use with the RA-4961 series receivers
• Wirelessly monitor windows, doors, or other areas
• Up to 1,000ft (305m) transmission range*
• Activates each time the door or window is moved
• Magnet can be placed on either side
• Adhesive mount — no screws required

Specifications

Wireless Alert System

• Frequency - 914.8MHz
• Channels - 1
• Transmission Range - Up to 1,000ft (305m)
• Power Supply - 2x CR2032 Batteries (Included)
• Current Draw - Standby- 8μA, Max- 80mA
• Estimated Battery Life - 132 days (@ 3 triggers/day)
• Low Battery Indicator - Zone LED on receiver blinks continuously
• Contact Distance - 3/8” (1cm)
• Sound Level - 96dB@1ft (30cm)
• Operating Temperature - -4°~140°F (-20°~60°C)
• Dimensions - Magnetic Contact- 1-7/8” x 1/4” x 4-3/16” (48 x 7 x 107 mm), Magnet- 3/8” x 1/4” x 1-9/16” (10 x 7 x 39 mm)

RA-4961-MCQ Datasheet
