GV-POE0812 Geovision 8-Port Gigabit 802.3at Web Management Layer 2+ Fully Managed PoE Switch

Features:

• Model Number: GV-POE0410-E
• Manufacturer SKU Number: 84-POE0410-E010
• Sales Part Number: 140-POE0410-E00
• 4-port PoE+ 10/100/1000BaseT(X), 1 Gigabit SFP
• IEEE 802.3at Compliant (4 Ports at Full 30W)
• Max. 130 W power consumption
• Extreme temperature support (?40°C ~ 70°C /?40°F ~ 158°F)
• Auto-MDI/MDI-X
• Auto-Negotiation

Specifications

Ports

• Number of Ports - 11 ports, including: 8-port 10/100/1000BaseT(X) with RJ-45 Connectors, PoE+ 2-port Gigabit Copper/SFP Combo Uplink Port 1-Console Port for CLI Management

Performance

• MAC Address - 8 K
• Buffer Memory - 4 Mbits
• Jumbo Frames - 9.6 KB
• Transmission Method - Store and Forward
• Transmission Media - 10/100BaseT(X) Cat. 5 UTP/STP    1000BaseT Cat. 5e, 6 UTP/STP
• Filtering/Forwarding Rates - 10 Mbps port - 14,880 pps 100 Mbps port - 148,800 pps 1000 Mbps port - 1,488,000 pps
• Backplane Capacity - 20 Gbps

Smart Features

• Layer supported - L2+ (DHCP Server, Static Routing)
• Port Based VLAN - 10
• Tag Based VLAN - 10, VID 1~4095
• IGMP Snooping - V1, V2 and V3
• Link Aggregation - up to 5 groups
• Quality of Service (QoS) - up to 8 queues, 802.1p, DSCP
• Port Management - Port State, Speed/Duplex, Flow Control Configuration, Port Mirroring , Broadcast Storm Control, Maximum Frame Size, Excessive Collision Mode, PoE
• Administrator Management - Command Line Interface (CLI), Web Based Management, Telnet, Access Management Filtering (SNMP, WEB, SSH, TELNET), SNMP (v1, v2c, v3), RMON (1, 2, 3, 9 groups), DHCP (Client, Relay, Option82, Snooping), System Event and Error Log, HTTP for Software Download and Upgrade, Configuration Download and Upload, sFlow, Port Mirroring (One to One, Many to One) Remote Ping, NTP, LLDP, UPnP, IPv6 Configuration
• L2+ Features - e Ping, NTP, LLDP, UPnP, IPv6 Configuration L2+ Features D

Mechanical Characteristics

• LED Indicators - Per Port, PoE, SFP, Power

Electrical Characteristics

• PoE Power - Input 100 ~ 240 V/AC, 50 ~ 60 Hz, Output IEEE 802.3at Compliant Voltage, Per Port Max. 30 watts (8 Ports at Full 15.4 W / 4 Ports at Full 30 W)
• Max. Power Consumption - 130 W

General

• Dimensions (H x W x D) - 1.73” x 12.99” x 8.26”
• Weight - 5.51 lb
• Operating Temperature - 0°C ~ 40°C (32°F ~ 104°F)
• Storage Temperature - -20°C ~ 90°C (-4°F ~ 194°F)
• Humidity - 5 to 90% RH (non-condensing)

Standards and Regulatory

• Standards - IEEE 802.3, 802.3u, 802.3ab, 802.3z, 802.3az EEE    IEEE 802.3x Flow Control IEEE 802.3ad Link Aggregation Control Protocol (LACP)    IEEE 802.1Q VLAN Tagging IEEE 802.1p Class of Service, Priority Protocols    IEEE 802.1D Spanning Tree Protocol IEEE 802.1w Rapid Spanning Tree Protocol IEEE 802.1s - Multiple Spanning Tree, IEEE 802.3at Power Over Ethernet (PoE+) IEEE 802.3af Power Over Ethernet (PoE) IEEE802.1v - Protocol VLAN IEEE 802.1AB - LLDP (Link Layer Discovery Protocol) IEEE 802.1X - Access Control
• Regulatory - CE, FCC Class A IEC 61000-4-5(Surge) Lv.5: Line to Line 2kV, Line to Ground 6kV

GV-POE0812 Datasheet
