EVAX-100ER Evax by Potter Voice Expander Panel 100W with DMR or Mic - Red

Features:

• Model Number: EVAX-100ER
• 25, 50, or 100 Watt Voice Evacuation Expander
• Microphone capable for voice communication
• Temporal whoop alarm tone
• Built-in power supply with battery charger
• 25 or 70 VRMS operation - field selectable with no additional parts required
• Power expansion of any Evax System
• Available as Expander Panels (model number EVAX Series), or as Expander Modules (model number EVX Series)
• Image shows gray but actual color is red

The Evax Systems Voice Evacuation System Expander Panels and Modules provide an easy and cost-effective way to increase the output power of an EVAX 25W voice evacuation system.

Specifications

• Primary Power - 24-30V AC/DC
• Current - 2.50A Alarm, 0.18 Standby
• Avg. Current Draw in Alarm - 2.5 A, 6.4A peak
• Output - 100 Watts
• Backbox Dimensions (WxHxD) - 14.5"x 18"x 4"
• Color - Charcoal Grey (Standard), Red (Optional)

EVAX-100ER Datasheet
