3992749 Potter RA-6500LG LCD Annunciator Flush Mount - LIGHT GRAY

• Model Number: RA-6500LG
• Item Number: 3992749
• Compatible with Potter IPA Series Panels
• Industry leading 4 line by 40 Character LCD
• Common buttons for navigation
• Common LEDs for status indication
• 31 annunciator per panel
• Maximum wire length of 6,500 feet

The RA-6500F is a flush mount LCD remote annunciator for the PFC series, Potter Plus series, and IPA series fire control panels. The RA-6500F communicates using a RS-485 connection to the main panel providing common indication of Alarms, Supervisory, Trouble and other system status and control functions.

Specifications

• Standby Current - 20 mA
• Alarm Current - 25 mA
• Operating Temperature - 0°C-49°C (32°F-120°F)
• Operating Humidity Range - 0 to 93% (non-condensing)
• Maximum Wire Length - 6500 ft.
• Maximum Annunciators - 31
• Flush Mount Size (WxHxD) - 11 3/8" x 9-1/4" x 7/8"
• Surface Mount Size (WxHxD) - 11 3/8" x 9-1/4" x 3 1/8"
• Wire Gauge - 12 AWG-22 AWG

3992749 Datasheet
